Our Services
Fabrication-ready steel detailing with zero ambiguity on the shop floor.
Get a Free QuoteOverview
Structural steel detailing is the process of creating fabrication and erection drawings from structural design models. Every bolt, weld, and connection must be precisely documented for the fabricator to produce and the erector to assemble. We deliver steel detailing that's ready for the shop — complete with connection details, material lists, bolt schedules, and erection sequences. Our models are coordinated with architectural and MEP systems to prevent field conflicts.
Connection Design
Detailed connection designs including bolted, welded, and moment connections.
Shop Drawings
Fabrication-ready drawings with all dimensions, materials, and connection details.
Erection Plans
Sequenced erection drawings with piece marks, crane picks, and assembly instructions.
Material Takeoffs
Accurate material lists and bolt schedules extracted directly from the model.
Our Process
We review structural design drawings and engineer's specifications.
Full structural steel model built with connections, bolts, and welds.
Shop drawings, erection plans, and GA drawings generated from the model.
Drawings submitted for engineer review with revisions tracked and managed.
FAQ
Get Started
Share your project details and we'll send you a fixed-price quote within 24 hours. No obligation, no hidden fees.
